Key Features
HIGH DIHEDRAL
The Vision has the highest amount of Dihedral in the Cabrinha range which helps greatly in upwind stability and reactive handling.
CONVEX STRUT
The Convex support strut on the Mantis V3 provides a stiffer and more reactive connection between the rider and wing.
20/20 VISION
A refined window layout, running parallel alongside the strut, made from weather resistant TPU provides increased visibility when riding.
FULL AIRFOIL
The full centre section airfoil increases the low end power helping you get up and going with minimal effort.
SIZE MATTERS
The small sizes excel in high winds due to the reactive sheeting, where are as the larger 6/7/8m were designed with lighter winds in mind to get you up and riding when most are sitting on the beach.
TIP TWIST
Progressive tip twist as the sizing increases in the Vision range helps keep sheeting relative and responsive no matter what size wing you ride.
NANO RIPSTOP
Nano Ripstop is a 55 g/m2 material with a 3mm double rip stop pattern. This micro rip stop material in unison with a newly developed coating, has given us a 2X increase in the canopy’s tear strength. A smaller rip stop pattern increases the amount of “cells” in any given panel.
KEYLOCK ANGLED HANDLE ATTACHMENTS
Indexing attachment points lock down the composite handles eliminating any rotation at each connection point. The culmination is the most rigid, direct handle design to date.
2 X SPRINT
Two sprint valves connection the Stiff Strut to the Leading edge allow for increased airflow to aid in both inflating and pack down.
TRAILING EDGE LOAD DISTRIBUTOR
The TE load distributor increases wing durability while robustly helping distribute wing tension throughout the trailing edge. The abrasive material stops scuffing while the wing rests on land.
PURE IMPULSE FRONT HANDLE V2
Expanding on the composite handle design, the all new Pure Impulse Front Handle gives the strongest, most direct LE control and handling in the market. Minute wrist control translates directly into wing input, allowing you to put the wing.
20/20 VISION
The new window positioning on the Mantis and Vision wings allows for increased range of visibility not only ahead, but also behind you, to aid during riding and transitions.
CONVEX STRUT
The new convex strut provides not only increased strength and stiffness, but also allows for a longer attachment between strut and canopy giving a clean fully tensioned profile at all angles of flight.
3D View
Style Selector
FREESTYLE
FREERIDE
BIG AIR
SURF
LIGHTWIND
RACE
WIND / WEIGHT CHART
Size | 2m | 2.5m | 3m | 3.5m | 4m | 4.5m | 5m | 6m | 7m | 8m |
---|---|---|---|---|---|---|---|---|---|---|
Wind Range in Knots (75kg rider) | 25-45 | 20-40 | 17-36 | 16-34 | 15-30 | 13-27 | 11-26 | 7-20 | 6-18 | 5-17 |
Weight of Wing (kg) Without Bag (Tolerances may vary) | 1.63 | 1.80 | 2.00 | 2.16 | 2.40 | 2.60 | 2.74 | 3.00 | 3.46 | 3.77 |
